Elprotronic S-GANG Programmer at TME
Simultaneous programming of up to 8 devices with internal memory.
TME has introduced the latest product from Elprotronic Inc. in the line of memory and microcontroller programming tools – S-GANG Standalone Gang Programmer. This efficient, versatile solution enables simultaneous programming of multiple devices. It is designed with production and testing applications in mind for a wide range of integrated circuits.
S-GANG-ISO-X-1 – S-GANG-ISO-X-1
S-GANG-ISO-X-8 – S-GANG-ISO-X-8
The new programmer allows for simultaneous programming of up to eight target devices (depending on the version selected) while maintaining full control over each (separate power lines, reset signal, and communication signals). The device operates both in standalone mode and under computer control. It allows for loading up to 60 different programs into its internal memory with a capacity of 120MB. It is compatible with Windows and Linux systems and offers PC communication via USB, Ethernet, and RS232 interfaces.
S-GANG supports a wide range of devices, mainly ARM architecture microcontrollers:
| Manufacturer | Supported families |
| Texas Instruments | MSPM0, MSP432, SimpleLink (ARM-based CC), TMxC |
| STMicroelectronics | STM32, BlueNRG |
| Silicon Labs | EFR32, EFM32, SiM3, EM_3xxx |
| Renesas | RA |
| NXP | Kinetis, LPC, K32L/W, S32K |
| Nordic Semiconductor | nRF |
| Microchip | SAMx |
| Maxim Integrated | MAX |
| Marvell | 88M |
| Infineon | FMx, PSoC |
| GigaDevice | GD32 |
| Analog Devices | ADuCM |
| Active-Semi | PAC |
Additionally, the device enables programming of Flash memory with SPI/QSPI serial interface (Cypress, GigaDevice, ISSI, Macronix, Microchip, Micron, Renesas, Winbond) and microcontrollers from the MSP430, STM8, AVR, PIC, RL78, and iMOTION families.
The programmer provides galvanic isolation and support for a wide range of target device voltages (1.65…5V DC).
It is worth noting that the S-GANG is also a scalable tool: several programmers can be connected and controlled from a single host, and the product offers features such as serialization, functional testing, and limiting the number of programming cycles.
Text prepared by Transfer Multisort Elektronik Sp. z o.o.
